Ice Core Records of Atmospheric CO2 Around the Last Three Glacial Terminations

( Go to original )

Science. 12 March 1999, Vol. 283. no. 5408, pp. 1712 – 1714; DOI: 10.1126/science.283.5408.1712
Authors: Hubertus Fischer, Martin Wahlen, Jesse Smith, Derek Mastroianni, Bruce Deck

ABSTRACT: Air trapped in bubbles in polar ice cores constitutes an archive for the reconstruction of the global carbon cycle and the relation between greenhouse gases and climate in the past. High-resolution records from Antarctic ice cores show that carbon dioxide concentrations increased by 80 to 100 parts per million by volume 600 ± 400 years after the warming of the last three deglaciations. Despite strongly decreasing temperatures, high carbon dioxide concentrations can be sustained for thousands of years during glaciations; the size of this phase lag is probably connected to the duration of the preceding warm period, which controls the change in land ice coverage and the buildup of the terrestrial biosphere.

Scripps Institution of Oceanography, Geosciences Research Division, University of California San Diego, La Jolla, CA 92093-0220, USA.


Previous studies of Antarctic ice cores (1-3) revealed that atmospheric CO2 concentrations changed by 80 to 100 parts per million by volume (ppmv) during the last climatic cycle and showed, together with continuous atmospheric measurements (4), that anthropogenic emissions increased CO2 concentrations from 280 ppmv during preindustrial times to more than 360 ppmv at present, an increase of more than 80% of the glacial-interglacial change. Variations in atmospheric CO2 concentrations accompanying glacial-interglacial transitions have been attributed to climate-induced changes in the global carbon cycle (5, 6), but they also amplify climate variations by the accompanying greenhouse effect. Accordingly, the relation of temperature and greenhouse gases in the past derived from ice core records has been used to estimate the sensitivity of climate to changes in greenhouse gas concentrations (7) to constrain the prediction of an anthropogenic global warming. This procedure, however, requires the separation of systematic variations representative for all climatic cycles from those specific for each event, as well as a more detailed knowledge of the leads and lags between greenhouse gas concentrations and climate proxies.

To resolve short-term changes in the atmospheric carbon reservoir, to constrain the onset and end of major variations in CO2 concentrations, and to test whether these variations are temporally representative, we expanded the Antarctic Vostok CO2 record over the transition from marine isotope stage (MIS) 8 to MIS 7 [about 210 to 250 thousand years (ky) before present (B.P.)] and analyzed the time interval around the penultimate deglaciation (about 70 to 160 ky B.P.) at a high resolution of 100 to 2000 years (8). This data set was supplemented by a CO2 record recently derived from the Antarctic Taylor Dome (TD) ice core (6, 9) covering the last 35,000 years. The internal temporal resolution of ice core air samples is restricted by the age distribution of the bubbles caused by the enclosure process (10). This age spread is about 300 years for Vostok (11) and 140 years for the TD ice core (9) at present but about three times higher for glacial conditions (11). The depth-ice age scale used for terminations II and III in the Vostok core is a recently expanded version of the extended glaciological time scale (12). The dating uncertainty (on the order of 10,000 years for termination III) is considerable; however, the absolute time scale is not so important as long as we consistently compare Vostok CO2 with the Vostok isotope temperature (Description: Description: Description: Description: Description: Description: Description: Description: cid:image002.gif@01CAC5C2.C1947620D) record.

More important is the relative dating of ice and air at a certain depth. The ice age-air age difference (Description: Description: Description: Description: Description: Description: Description: Description: cid:image003.gif@01CAC5C2.C1947620age) was calculated with a climatological firn densification model (11) and varies between about 2000 and 6000 years for warm and cold periods, respectively. The accuracy of the model is better than 100 years for recent periods but on the order of 1000 years for glacial conditions (11), which has to be kept in mind when interpreting the phase shift between ice and gas records of the ice core archive. In the case of termination I, recently published age scales derived by synchronization of CH4 variations in central Greenland and Antarctic ice cores (13, 14) were used. The precision of the CH4 correlation is about 200 years for periods of substantial CH4 change but is not very well constrained in the interval between 17 and 25 ky B.P., when only subtle CH4 changes occurred. The uncertainty of Description: Description: Description: Description: Description: Description: Description: Description: cid:image003.gif@01CAC5C2.C1947620age varies between 100 and 300 years for central Greenland (13) and between 300 and 600 years for TD (14) during termination I. Further uncertainty is added because the TD CO2 record has been dated relative to the Greenland Ice Sheet Project 2 (GISP2) core (14), whereas the Byrd and Vostok isotope temperature records have been synchronized with respect to the Greenland Ice Core Project (GRIP) ice core record (13). This uncertainty is not relevant for the interval between 10 and 15 ky B.P., for which dating of GISP2 and GRIP is in good agreement; however, there is a shift of up to 2000 years between the two Greenland reference cores at the age of 20 ky B.P.

In Fig. 1, our data and previously published CO2 concentration records (1, 6, 9, 11, 15, 16) are compared with Antarctic isotope (temperature) ice core records (13, 17-19). Note that the CO2 concentrations represent essentially a global signal. In contrast, the geographical representativeness of isotope temperature records may vary from a synoptical to hemispherical scale and accordingly within different cores with increasing variability for shorter time scales. The Vostok and TD CO2 data presented here are in good agreement with previous CO2 values. On a 10,000-year time scale, CO2 covaries with the isotope temperatures with minimum glacial CO2 concentrations of 180 to 200 ppmv, glacial-interglacial transitions accompanied by a rapid increase in CO2 concentrations to a maximum of 270 to 300 ppmv, and a gradual return to low CO2 values during glaciation. On a shorter time scale, however, a much more complex picture evolves. Description: Description: Description: Description: Description: Description: Description: Description: http://www.sciencemag.org/content/vol283/issue5408/images/small/se0897290001.gif


Fig. 1. Records of atmospheric CO2 concentrations and isotope temperature records derived from the Antarctic Byrd, Vostok, and TD ice cores during the deglaciation and glaciation events around the last three glacial terminations. Error bars in CO2 concentration data represent 1Description: Description: Description: Description: Description: Description: Description: Description: cid:image005.gif@01CAC5C2.C1947620 of replicate measurements at the same depth interval. The long-term trend in CO2 concentrations is indicated by a cubic spline approximation (P = 5 × 10Description: Description: Description: Description: Description: Description: Description: Description: cid:image006.gif@01CAC5C2.C19476209) of our data set. For convenience, marine isotope stages (22) are indicated as referred to in the text. [View Larger Version of this Image (48K GIF file)]


The onset of the atmospheric CO2 increase during termination I recorded in the TD record is at 19 to 20 ky B.P. The rise in the long-term trend in CO2 concentrations seems to be about 1000 years earlier than the rise in Vostok Description: Description: Description: Description: Description: Description: Description: Description: cid:image002.gif@01CAC5C2.C1947620D values. In contrast, temperatures apparently started to rise at 20 ky B.P., as recorded in the Antarctic Byrd and the Greenland GRIP ice core (13). Again, CO2 concentrations in the Byrd record increase ~2000 ± 500 years later than those in the TD data. In view of the excellent agreement for the rest of the CO2 records, these discrepancies can be attributed to the insufficient age constraint during the onset of termination I induced by the different Greenland reference cores. No such dating uncertainties are encountered for the interval between 10 and 15 ky B.P. Maximum CO2 concentrations of 270 ppmv are reached at 10.5 ky B.P. (9), 600 to 1000 years after the isotope temperature maximum in the Byrd record (20). The CO2 peak is followed by a decrease of 5 to 10 ppmv until 8 ky B.P., after which CO2 concentrations gradually rise to the preindustrial value of 280 ppmv (9). A delay in the increase of CO2 concentrations with respect to the warming during deglaciation is also indicated by a brief 10-ppmv decline in CO2 concentrations found in seven samples during the interval 14 to 13 ky B.P. This distinct feature lags the Antarctic Cold Reversal (ACR) in the Antarctic isotope temperatures (21) by 300 to 500 years but occurs 1000 years before the Younger Dryas cooling event.

A dip in CO2 concentrations at 135 ky B.P. precedes the start of the increase in CO2 concentrations during termination II, which reaches a maximum of 290 ppmv at 128 ky B.P. Like in the Holocene, CO2 concentrations decrease after this initial maximum to ~275 ppmv. The onset of the major warming during termination II is hard to define, but during the penultimate warm period, CO2 concentrations reach their maximum 400 ± 200 years later than Antarctic temperatures. In the following 15,000 years of the Eemian warm period, CO2 concentrations do not show a substantial change despite distinct cooling over the Antarctic ice sheet. Not until 6000 years after the major cooling in MIS 5.4 does a substantial decline in CO2 concentration occur. Another 4000 to 6000 years is required to return to an approximate in-phase relation of CO2 with the temperature variations.

Finally, termination III starts with a CO2 concentration of 205 ppmv at 244 ky B.P., slightly higher than that for the beginnings of terminations I and II. At that time, temperatures had already increased since the glacial temperature minimum at ~260 ky B.P. CO2 concentrations rise slowly from 244 to 241 ky B.P. and then rapidly to more than 300 ppmv at 238 ky B.P. Keeping the rather coarse resolution of the Description: Description: Description: Description: Description: Description: Description: Description: cid:image002.gif@01CAC5C2.C1947620D record before 238 ky B.P. in mind, the major increase in CO2 tends to lag temperature during the transition, reaching a maximum CO2 concentration 600 ± 200 years after the peak in Description: Description: Description: Description: Description: Description: Description: Description: cid:image002.gif@01CAC5C2.C1947620D. In contrast to the case for the Eemian, high CO2 concentrations are not sustained during MIS 7 but follow the rapid temperature drop into MIS 7.4. Minimum CO2 concentrations as low as 210 ppmv are reached 1000 to 2000 years after the minima in isotope temperature during MIS 7.4. A short, warm event during the mild glacial interval at 224 to 228 ky B.P. appears to be reflected in a 30-ppmv increase in atmospheric CO2 concentrations with a phase lag of about 1000 ± 600 years relative to temperature. Another warm event at the beginning of the warm period MIS 7.3 is accompanied by a 30-ppmv increase in CO2 concentration, which appears to be in phase with the temperature record. The variations in CO2 concentrations during these events are much larger than anticipated from the Vostok isotope temperature changes and do not have any counterparts during MIS 5.

Comparison of the sequence of events for the three time intervals described above suggests that the carbon cycle-climate relation should be separated into (at least) a deglaciation and a glaciation mode. Atmospheric CO2 concentrations show a similar increase for all three terminations, connected to a climate-driven net transfer of carbon from the ocean to the atmosphere (6). The time lag of the rise in CO2 concentrations with respect to temperature change is on the order of 400 to 1000 years during all three glacial-interglacial transitions. Considering the uncertainties in Description: Description: Description: Description: Description: Description: Description: Description: cid:image003.gif@01CAC5C2.C1947620age (between 100 and 1000 years for recent and glacial conditions), such a lag can still be explained by an overestimation of Description: Description: Description: Description: Description: Description: Description: Description: cid:image003.gif@01CAC5C2.C1947620age for glacial conditions. The good agreement of the Description: Description: Description: Description: Description: Description: Description: Description: cid:image003.gif@01CAC5C2.C1947620age model with the measured value for the present supports the idea that at least the lag at the beginning of the warm periods is real. The size of this lag is on the order of the ocean mixing time (for a well-ventilated ocean like today), which is the major control for the time constant of equilibration within the deep ocean-atmosphere carbon system after climate-induced changes. In the case of a recent anthropogenic warming, the external climate forcing by CO2 emissions due to combustion of fossil fuel leads climate variations, so the application of the CO2-climate relation deduced from the past on a recent global warming seems not to be straightforward.

The situation is even more complicated for the interglacial and glaciation periods. During the extended Holocene and Eemian warm periods, atmospheric CO2 concentrations drop by ~10 ppmv after an initial maximum, attributable to a substantial increase in the terrestrial biospheric carbon storage extracting CO2 from the atmosphere. In the case of the Eemian, CO2 concentrations remain constant after the initial maximum in MIS 5.5 despite slowly decreasing temperatures; during the Holocene, atmospheric CO2 concentrations even increase during the last 8000 years. Application of a carbon cycle model to CO2 and Description: Description: Description: Description: Description: Description: Description: Description: cid:image002.gif@01CAC5C2.C194762013CO2 ice core data for the Holocene (9) shows that no equilibrium in the carbon cycle is established and that the waxing and waning of the terrestrial biosphere, possibly related to subtle climate variations and early human land use, are the most important factors controlling atmospheric CO2 concentrations over the last 10,000 years.

During further glaciation in MIS 5.4, CO2 concentrations remain constant, although temperatures strongly decline. We suggest that this reflects the combination of the increased oceanic uptake of CO2 expected for colder climate conditions and CO2 release caused by the net decline of the terrestrial biosphere during the glaciation and possibly by respiration of organic carbon deposited on increasingly exposed shelf areas. These processes, however, should terminate (with some delay) after the lowest temperatures are reached in MIS 5.4 and ice volume is at its maximum at 111 ky B.P. (22). In agreement with this hypothesis, CO2 concentrations start to decrease in the Vostok record at about 111 ky B.P. Another possibility to explain this delayed response of CO2 to the cooling during MIS 5.4 would be an inhibited uptake of CO2 by the ocean. In any case, about 5°C lower temperatures on the Antarctic ice sheet during MIS 5.4 (17) are difficult to reconcile with the full interglacial CO2 forcing encountered at the beginning of this cold period and again question the straightforward application of the past CO2-climate relation to the recent anthropogenic warming.

Another scenario is encountered during MIS 7, in which no prolonged warm period is observed. Although temperatures at the end of termination III are comparable to those at the end of termination II and CO2 concentrations are even slightly higher, a much shorter lag in the decrease of CO2 relative to the Antarctic temperature decrease in MIS 7.4 is found. Comparison with the SPECMAP record (23) shows that during the preceding interglacial MIS 7.5, ice volume was much larger than during the Holocene and the Eemian warm periods. Accordingly, the buildup of the terrestrial biosphere during MIS 7.5 is expected to be much less and sea level changes smaller, leading to a smaller net release of CO2 into the atmosphere during the following glaciation, which is not able to fully counterbalance the CO2 uptake by the ocean.

REFERENCES AND NOTES

J. M. Barnola, D. Raynaud, Y. S. Korotkevich, C. Lorius, Nature 329, 408 (1987) .

A. Neftel, E. Moor, H. Oeschger, B. Stauffer, ibid. 315, 45 (1985) .

D. Raynaud, et al., Science 259, 926 (1993) [Free Full Text] . Recent investigations in central Greenland have reported an in situ production of CO2 in the ice, possibly related to carbonate or organic species reactions (or both), and have strongly compromised the validity of the determined CO2 concentrations. However, Antarctic ice cores are (if at all) much less affected by this effect because of the very low abundance of reactive carbon species dissolved in Antarctic ice.

C. D. Keeling, T. P. Whorf, M. Wahlen, J. van der Pflicht, Nature 375, 666 (1995) [CrossRef] .

M. Leuenberger, U. Siegenthaler, C. C. Langway, ibid. 357, 488 (1992) [CrossRef].

H. J. Smith, H. Fischer, M. Wahlen, D. Mastroianni, B. Deck, in preparation.

C. Lorius, J. Jouzel, D. Raynaud, J. Hansen, H. Le Treut, Nature 347, 139 (1990) .

M. Wahlen, D. Allen, B. Deck, A. Herchenroder, Geophys. Res. Lett. 18, 1457 (1991) . Air samples were extracted from Vostok 5G and TD ice with a dry extraction technique, and CO2 concentrations were determined with laser spectroscopy. The accuracy of a single measurement (as essentially determined by the standard deviation of multiple frequency tunings of the diode laser) is better than 5 ppmv. The laser spectroscopic method enables the use of very small samples (~4 g), allowing us to pick crack-free ice and to measure replicate samples at the same depth interval. In general, all given CO2 concentrations correspond to the average and standard deviation of at least three replicate samples. On average, the variability of such replicate measurements is 7.5 ppmv (1Description: Description: Description: Description: Description: Description: Description: Description: cid:image005.gif@01CAC5C2.C1947620).

A. Indermühle et al., Nature, in press.

J. Schwander, et al., J. Geophys. Res. 98, 2831 (1993) .

J.-M. Barnola, P. Pimienta, D. Raynaud, Y. S. Korotkevich, Tellus Ser. B 43, 83 (1991) [CrossRef].

Expanded ice age and air age time scales were kindly provided by J. Jouzel and J.-R. Petit. Ages were assigned to sample depths after slight depth corrections for the Vostok 5G core (17) by linear interpolation of the depth-age scale. A publication describing the calculation of the expanded time scales, which is essentially based on the procedure described by J. Jouzel et al. [Nature 364, 407 (1993)], is in preparation.

T. Blunier, et al., Nature 394, 739 (1998) [CrossRef] .

E. J. Steig, et al., Science 282, 92 (1998) [Abstract/Free Full Text] .

A. Neftel, H. Oeschger, T. Staffelbach, B. Stauffer, Nature 331, 609 (1988) .

B. Stauffer, et al., ibid. 392, 59 (1998) [CrossRef].

J. Jouzel, et al., Clim. Dyn. 12, 513 (1996) .

J. R. Petit, et al., Nature 387, 359 (1997) [CrossRef] .

S. J. Johnsen, W. Dansgaard, H. B. Clausen, C. C. Langway Jr., ibid. 235, 429 (1972) [CrossRef] [Web of Science].

Phase relations were determined by comparison of maxima and minima in the long-term trend of CO2 concentrations and isotope temperatures as represented by spline approximations. Given errors reflect the uncertainty in the actual positions of the extrema, which are weakly dependent on the degree of smoothing. They do not take into account the uncertainty in Description: Description: Description: Description: Description: Description: Description: Description: cid:image003.gif@01CAC5C2.C1947620age. This additional error is treated separately in the discussion of the data.

T. Blunier, et al., Geophys. Res. Lett. 24, 2683 (1997) [CrossRef] [Web of Science].

D. G. Martinson, et al., Quat. Res. 27, 1 (1987) .

J. Imbrie et al., in Milankovitch and Climate, A. Berger et al., Eds. (Reidel, Hingham, MA, 1984), pp. 269-305.

We thank J.-M. Barnola and D. Raynaud for helpful comments and for sharing with us their unpublished Vostok CO2 record of the last four glacial-interglacial cycles during our sample selection process. This study was funded by NSF grants OPP9615292, OPP9196095, and OPP9118534. Financial support of H.F. has been provided by Deutsche Forschungsgemeinschaft.

30 November 1998; accepted 29 January 1999
